Dell XPS 200 User Manual
Page 79
Removing and Installing Parts
79
NOTE:
The interface cable is held in place by the metal drive bracket and does not need to be removed
from the drive.
4 Disconnect the interface cable from the interface cable connector on the system board (see
drive release
latch
CD/DVD drive
interface cable
interface cable
connector
