Dell XPS 200 User Manual
Page 71
Removing and Installing Parts
71
8 Place the card in the connector and press down firmly. Ensure that the card is fully seated in
the slot.
9 Before you close the card retention door, ensure that:
•
The tops of all cards and filler brackets are flush with the alignment bar.
•
The notch in the top of the card or filler bracket fits around the alignment guide.
card fully
seated
card not fully
seated
bracket caught
outside of slot
bracket
within slot
