8

About Your Monitor
Back View
1
2
3
4
5
6
7
Back view Back view with monitor stand
Label Description Use
1 VESA mounting holes
(100 mm x 100 mm -
behind attached VESA
Cover)
Wall mount monitor using VESA-
compatible wall mount kit (100 mm x
100 mm).
2 Regulatory label Lists the regulatory approvals.
3 Security lock slot Secures monitor with security cable
lock.
4 Barcode serial number
label
Refer to this label if you need to contact
Dell for technical support.
5 Stand release button Release stand from monitor.
6 USB downstream port
with battery charging
Connect your USB device. You can only
use this connector after you have
connected the USB cable to the
computer and USB upstream connector
on the monitor.
7 Cable management slot Use to organize cables by placing them
through the slot.
