Dell UP2414Q Monitor - Manual (Page 10)

10

About Your Monitor
Monitor Specifications
Flat Panel Specifications
Screen type Active matrix - TFT LCD
Panel type In Plane Switching
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
60.47 cm (23.8-inches viewable image size)
527.04 mm (20.7 inches)
296.46 mm (11.7 inches)
156246.28 mm
2 (242.2 inches 2 )
Pixel pitch 0.137 mm
PPI (Pixel per inch) 185 ppi
Viewing angle 178° (vertical) typ, 178° (horizontal) typ
Luminance output 350 cd/m² (typ)
Contrast ratio 1000:1 (typ)
Dynamic Contrast ratio 2,000,000:1
Faceplate coating Antiglare with hard-coating 3H
Backlight LED edge light system
Response Time 8 ms (GtG typical)
Color depth 1.07 Billion colors, 8 Bits + A-FRC
Color gamut (Typical) 100% (sRGB) 99% (Adobe RGB)
Resolution Specifications
Horizontal scan range 30 kHz to 140 kHz (automatic)
Vertical scan range 24 Hz to 75 Hz (automatic)
Maximum resolution 3840 x 2160 at 60 Hz DP 1.2*
3840 x 2160 at 30 Hz HDMI
* To display 3840 x 2160 at 60 Hz, DP1.2 must be enabled and the DP
source’s graphics card must be DP1.2 certified with MST feature, capable of
supporting resolution up to 3840 x 2160 at 60Hz and its driver supports
DisplayID v1.3.
Video Supported Modes
Video display capabilities (HDMI playback) 480p, 576p, 720p and 1080p
