Page 12

1-8

2-Post Rack Installation

www

.dell.com | support.dell.com

F i g u r e 1 - 4 .

I n s t a l l i n g t h e S l i d e A s s e m b l i e s f o r C e n t e r - M o u n t

C o n f i g u r a t i o n

12-24 x 0.5-inch pan-
head Phillips screw
(5 per slide assembly)

two-post open-frame rack

slide assembly

slide release
latch (green)

nuts (2 per bracket)

system release
latch (yellow)

stiffening bracket

holes for stiffening
bracket with 6-inch racks

front bracket

back bracket

holes for
stiffening
bracket with
3-inch racks
