20
Table 1-4. Table Temperature Thresholds ( continued )
Temperature Sensor Number UNCT UCT
P1_DIMM_TEMP 0x4D 96 98
Chassis_Ambient 0x54 48 50
Outlet_TEMP 0x42 N/A N/A
Table 1-9. Voltage Thresholds
Voltage Sensor Sensor
Number
Normal LCT LNCT UNCT UCT
CPU_0_Vcore 0x10 1.00V N/A N/A N/A N/A
CPU_1_Vcore 0x11 1.00V N/A N/A N/A N/A
DDRP0_Voltage 0x12 1.5V 1.349V 1.388V 1.599V 1.646V
DDRP1_Voltage 0x13 1.5V 1.349V 1.388V 1.599V 1.646V
DDRP0_Voltage (LV) 0x12 1.35V 1.209V 1.248V 1.443V 1.482V
DDRP1_Voltage (LV) 0x13 1.35V 1.209V 1.248V 1.443V 1.482V
P5V 0x28 5V 4.472V 4.628V 5.330V 5.486V
P3V3 0x15 3.3V 2.958V 3.062V 3.526V 3.629V
Table 1-10. Current Thresholds
Current Sensor Sensor
Number
LCT LNCT UNCT UCT
MB_12V_Current 0xCA N/A N/A N/A N/A
PSU1_OUT_Current 0x70 N/A N/A N/A N/A
PSU2_OUT_Current 0x71 N/A N/A N/A N/A
Table 1-11. Fan Thresholds
Fan Sensor Sensor Number LCT LNCT UNCT UCT
FCB Fan 1 0x6B 1000 1200 N/A N/A
FCB Fan 2 0x6C 1000 1200 N/A N/A
FCB Fan 3 0x6D 1000 1200 N/A N/A
FCB Fan 4 0x6E 1000 1200 N/A N/A
