(typical)
Stand by Blanked Off after 30minutes of no signal < 3W Amber
Power switch off Active/Blanked Off < 1W OFF
This monitor is E NERGY S TAR®-compliant as well as TCO '99 power management compatible.
* Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the monitor.
E NERGY S TAR® is a U.S. registered mark. As an E NERGY S TAR® Partner, DELL has determined that this product meets the
E NERGY S TAR® guidelines for energy efficiency.
NOTE: This LCD TV automatically returns to normal operation when horizontal and vertical sync return, which occurs when
you move the computer's mouse or press a key on the keyboard.
Pin Assignments
15-pin D-Sub connector:
Pin Number LCD TV Side of the 15-Pin Side Signal Cable
1 Red
2 Green
3 Blue
4 GND
5 Self test
6 Red GND
7 Green GND
8 Blue GND
9 +5V (supply form PC)
10 Sync GND
11 GND
