Dell Latitude E6420 XFR Setup and Features Information
Smart Cards | Page 13
3 Connect USB devices, such as a mouse or keyboard. (optional)
Figure 6. USB Connector
4 Open the computer display and press the power button to turn on the computer.
Figure 7. Power Button
NOTE: It is recommended that you turn on and shut down your computer at least once before
you install any cards or connect the computer to a docking device or other external device,
such as a printer.
Smart Cards
There are two main types of Smart or Common Access Cards (CAC):
1 Enclosed Smart Cards ( ) — these cards have a contact area with many gold plated
connection pads. When inserted into a card reader, the information from the chip can be
read and written.
The Enclosed Smart Card is accessed through the left front side door above the hard drive.
Enclosed Smart Card Reader
