Installing System Components
95
13 Connect the control-panel interface cable to the FP_CONN1 connector
on the system board. See Figure 6-2 for the location of the FP_CONN1
connector.
14 If applicable, connect the optical drive interface cable to the SATA_2
connector on the system card. See Figure 6-2 for the location of the
SATA_2 connector.
15 Install the cooling shroud. See "Installing the Cooling Shroud" on page 57.
16 Close the system. See "Closing the System" on page 55.
