58 | Removing the Power-Adapter Port
Procedure
1 Release the power-adapter port cable from the routing guides on the computer
base.
2 Remove the screw that secures the power-adapter port to the base.
3 Lift the power-adapter port, along with its cable, off the computer base.
1 screw 2 power-adapter port
3 power-adapter port cable 4 routing guides
1 4
3
2
