Figure 6. 64 Servers Connected to Two Controllers
The following figure shows up to 64 stand-alone servers attached (using multiple sessions) to a single
RAID controller module through a network using a 10G aggregation scheme. The NICs on the servers are
0 G NICs and the uplink ports are 10G. Hosts that have a second Ethernet connection to the network
allow two separate physical paths for each host, which ensures full redundancy if one of the paths fails. It
is recommended you use two switches for more redundancy. However, single switch configuration is
also supported.
