System Board
Dell™ OptiPlex™ GX50 Systems
System Board Components
1
Floppy drive connector
13 Front-panel audio connector
2
Battery
14 Video connector (upper) and audio connectors (lower)
3
EIDE2 connector
15 Modem connector
4
EIDE1 connector
16 Network connector (upper) and USB connectors (2) (lower)
5
Front panel connector
17 Keyboard (lower) and mouse (upper) connectors
6
PCI riser board (small mini-tower computer only) 18 Diagnostic lights
