Display 63
3 Remove the display bezel (see "Removing the Display Bezel" on page 57).
4 Remove the hinge caps (see "Removing the Hinge Caps" on page 61).
5 Remove the four screws (two on each side) that secure the display panel
brackets to the display panel.
Replacing the Display Panel Brackets
1 Follow the instructions in "Before You Begin" on page 9.
2 Align the screw holes on the display panel vbbrackets with the screw holes
on the display panel.
3 Replace the four screws (two on each side) that secure the display-panel
brackets to the display panel.
4 Replace the hinge caps (see "Replacing the Hinge Caps" on page 62).
5 Replace the display bezel (see "Replacing the Display Bezel" on page 58).
1 display panel brackets (2) 2 screws (4)
1
2
