62 Display
Replacing the Hinge Caps
1 Follow the instructions in "Before You Begin" on page 9.
2 Align the tabs on the hinge caps with the slots on the display panel
brackets and snap them into place.
3 Turn the display panel over and place it on the display cover.
4 Replace the six screws that secure the display panel to the display cover.
5 Replace the display bezel (see "Replacing the Display Bezel" on page 58).
6 Replace the display assembly (see "Replacing the Display Assembly" on
page 56).
CAUTION: Before turning on the computer, replace all screws and ensure that no
stray screws remain inside the computer. Failure to do so may result in damage to
the computer.
Display Panel Brackets
Removing the Display Panel Brackets
1 Follow the instructions in "Before You Begin" on page 9.
2 Remove the display assembly (see "Removing the Display Assembly" on
page 53).
1 display hinges (2) 2 hinge caps (2)
2 1
