8 Document Classification (for non-Titus systems) | DL4XXX - Fibre Channel Implementation | Document numbers,
revision numbers, and other document identifiers can be placed in the footer.
2. Within the console, select Port 1 and Port 2 and inventory their port WWNs.
QLogic 2562 HBA
Port 1 Port 2
21-00-00-24-FF-59-e9-1C 21-00-00-24-FF-59-E9-1D
Identify and document the WWN’s of the MD3600f storage array. The MD3600f has four fibre channel ports on
both controller-1 and controller-2.
3. Within MSDM, select the Summary Tab, then select View Storage array Profile. Select the Hardware
tab, then the RAID Controller Modules sub-tab. Scroll down and catalog the port WWNs of each
controller.
Controller-0 Controller-1
Port-0 20:14:c8:1f:66:c8:f3:da 20:15:c8:1f:66:c8:f3:da
Port-1 20:24:c8:1f:66:c8:f3:da 20:25:c8:1f:66:c8:f3:da
Port-2 20:34:c8:1f:66:c8:f3:da 20:35:c8:1f:66:c8:f3:da
Port-3 20:44:c8:1f:66:c8:f3:da 20:45:c8:1f:66:c8:f3:da
