Using the E-Flat Panel Stand
FILE LOCATION: C:\Documents and Settings\julie_Woodson\My
Documents\eDocs\Edocks\efpl\en\Source\using.fm
DELL CONFIDENTIAL – PRELIMINARY 7/22/08 - FOR PROOF ONLY
If your monitor is 15 inches or smaller:
a Use the four holes that are closer to the center of the VESA adapter
plate (diameter measures 75 mm x 75 mm between the holes).
b Insert the caps in the other four holes on the VESA adapter plate.
c Attach your monitor to the VESA adapter plate.
2 3
4
5
1
