Using the E-Flat Panel Stand
15
FILE LOCATION: C:\Documents and Settings\julie_Woodson\My
Documents\eDocs\Edocks\efpl\en\Source\using.fm
DELL CONFIDENTIAL – PRELIMINARY 7/22/08 - FOR PROOF ONLY
Adjusting the Flat Panel Monitor
NOTICE:
If you have a laptop docked in the flat panel stand, angle the monitor up
and ensure it is clear of your laptop before you change the monitor from landscape
to portrait orientation.
You can adjust your monitor on the flat panel stand in the following ways:
• Angle the monitor up or down.
• Raise or lower the height of the monitor.
• Rotate the monitor to the left or right.
• Rotate the monitor to landscape or portrait orientation.
1 caps (4) 2 VESA adapter plate
3 screw holes for monitor larger than 15
inches (4) 4 flat panel monitor
5 flat panel stand
