Disconnecting a Port Replicator From the Flat
Panel Stand
1 Disconnect all cables from the port replicator.
2 Press the release button on the back of the flat panel stand, and then lift
the front of the port replicator to release it from the release tab on the flat
panel stand.
3 Remove the port replicator from the flat panel stand.
1 release button
1
