8
Using the E-Flat Panel Stand
FILE LOCATION: C:\Documents and Settings\julie_Woodson\My
Documents\eDocs\Edocks\efpl\en\Source\using.fm
DELL CONFIDENTIAL – PRELIMINARY 7/22/08 - FOR PROOF ONLY
Adjusting the Weight Limit for a Flat Panel
Monitor
The default weight limit for the flat panel monitor is set for a 17-inch to 20-
inch monitor. If your monitor is 20 inches to 24 inches, adjust the weight
limit setting on the flat panel stand.
1 Remove the tool from the base of the flat panel stand.
2 Insert the tool into the weight limit slot.
3 Turn the tool counter-clockwise to point the arrow to the 20 to 24-inch
setting.
1 magnified weight limit 2 weight limit slot
3 weight limit adjustment tool
2
1
3
