Bottom view – Dell 2408WFP Monitor User Manual
Page 4
Bottom View
Bottom view
Right side
Left side
Label Description
1
2
USB downstream ports
Label Description
1
AC power cord connector
2
DC power connector for Dell™ Soundbar
3
DisplayPort connector
4
HDMI connector
5
DVI connector-1
6
DVI connector-2
7
VGA connector
8
Composite video connector
9
S-Video connector
10
Component video connectors
11
Audio out
12
USB upstream port
13
USB downstream ports
