Setting Up the Monitor
Dell™ 2408WFP Flat Panel Monitor
User's Guide
Attaching the Soundbar (optional)
Attaching the Stand
Place the stand on a flat surface and follow these steps to attach the monitor stand:
1.
Fit the groove on the back of the monitor to the two tabs on the upper part of the stand.
2.
Lower the monitor so that the monitor mounting area snaps on to or locks on to the stand.
Connecting Your Monitor
To connect your monitor to the computer perform the following steps/instructions:
l
Turn off your computer and disconnect the power cable.
l
Connect either the white (digital DVI-D) display connector cable, the blue (analog VGA) display connector cable or the black DisplayPort cable to the
corresponding video port on the back of your computer. Do not use
all the cables on the same computer. Use all the cables only when they are
connected to different computers with appropriate video systems.
Connecting the white DVI cable
NOTE:
The stand is detached when the monitor is shipped from the factory.
CAUTION:
Before you begin any of the procedures in this section, follow the
safety instructions
.
