Dell Latitude D820 - Manual (Page 80)

Network adapter RJ-45 port
D-Dock Standard D-dock connector for devices such as D-
Docks advanced port replicators and expansion
stations.
Communications
Modem:
Type v.92 56K MDC
Controller softmodem
Interface Intel HDA bus
Network adapter 1 Gb Ethernet LAN on system board
Wireless internal WLAN, WWAN, and Bluetooth® wireless
support (if optional cards are purchased)
Graphics
Graphics type Pixel Shader 3.0
Data bus PCI Express
Controller/ Memory NVidia G72MV on 128-MB video memory
NVidia G72M on 256-MB video memory
LCD interface LVDS
TV support NTSC or PAL in S-video and composite modes
(through dock only)
Audio
Audio type High Definition Audio (Soft Audio)
Audio controller SigmaTel STAC9200
Stereo conversion 24-bit (stereo digital-to-analog),
24-bit (stereo analog-to-digital)
Interfaces:
Internal PCI bus/HDA
External microphone miniconnector, stereo
headphones/speakers miniconnector
Speaker two 4-ohm speakers
Internal speaker amplifier 2-W channel into 4ohms
Volume controls keyboard shortcuts or program menus
Display
Type (active-matrix TFT) WXGA, WSXGA+, or WUXGA
Dimensions:
Height 222.5 mm max (8.7 inches)
Width 344.5 mm (13.56 inches)
Diagonal 391.16 mm (15.4 inches)
Operating angle 0° (closed) to 180°
Viewing angles:
WXGA horizontal 40/40°
WXGA vertical 10/30°
WSXGA+ horizontal 65/65°
WSXGA+ vertical 50/50°
WUXGA horizontal 65/65°
WUXGA vertical 50/50°
Pixel pitch:
WXGA 0.2588 (15.4-inch)
WSXGA+ 0.1971 (15.4-inch)
WUXGA 0.1725 (15.4-inch)
Power consumption (panel with backlight) (typical):
