support.dell.com Using the Dell PowerVault Switch Manager 2-19
Port Status field No_Module — No GBIC module in this port
No_Light — The module is not receiving light
No_Sync — The module is receiving light but is out
of sync
In_Sync — The module is receiving light and is in
sync
Laser_Flt — The module is signaling a laser fault
(defective GBIC)
Port_Flt — The port is marked faulty (defective
GBIC, cable, or device)
Diag_Flt — The port failed diagnostics
Online — The port is up and running
Lock_Ref — The port is locking to the reference
signal
Port Type field E-Port — Switch link port
G-Port — Generic port
U-Port — Universal port
F-Port — Fabric port
FL-Port — Fabric loop port
L-Port — Loop port
PortStats tab
4-Byte Word
Transmitted field Number of four-byte words transmitted
4-Byte Word
Received field Number of four-byte words received
Frames Transmit-
ted field Number of frames transmitted
Frames Received
field Number of frames received
C2 Frames
Received field Number of class 2 frames received
C3 Frames
Received field Number of class 3 frames received
* +
,(
