support.dell.com Using the Dell PowerVault Switch Manager 2-15
)
%
)
%
Port icon Indicates gigabit interface converter (GBIC) type:
ID — Serial ID GBIC
CU — Copper
SW — Short wave
LW — Long wave
Blank — No GBIC present
A yellow outline around the port icon indicates a port
failure
For detailed port information, click the port icon for the
Port Statistics window
Number icon Number of the port
