Dell PowerVault Switch Manager User’s Guide

!# "

The fabric topology window shows the physical configuration of the fabric including
active domains and paths. The topology is shown as viewed from the host domain
(the switch initially requested from the web browser). To access this screen, click
Fabric Topology from the Fabric View.

NOTE: Each switch in a fabric is a domain with its own unique domain ID.

Figure 2-2 shows the fabric topology window. Table 2-2 provides a description for
each component in this window.

Name Server Table
button

Opens to the Name Server Table window

Zone Administration
button

Opens the Zone Administration window
