Figure 2-4, Zone alias settings screen -9, Table 2-4 – Dell PowerVault 57F User Manual

Page 19: Zone alias settings fields -9, Figure 2-4 s, En. table 2-4 p

support.dell.com

Using the Dell PowerVault Switch Manager

2-9

# $%

Alias Name field

Displays the currently selected alias.

Create Alias button

Click to enter the name of a new alias; all names must
be unique and contain no spaces.

Delete Alias button

Click to delete an alias appearing in the Alias Name
field.

Rename Alias button

Click to enter a new name for the currently selected
alias.

Member Selection
List field

Displays a list of available switches, ports, and WWNs.

Add Member button

Select a member from the Member Selection List and
click Add Member to add to the list of members for the
currently selected alias.

Remove Member but-
ton

Select a member from a list of members for the cur-
rently selected alias and click Remove Member to
remove from the member list.
