Page 13
8.
Lift the display assembly out of the computer base.
Installing the Display Assembly
1.
Align the display assembly over the screw holes in the base of the computer.
2.
Replace the four M2.5 x 5-mm screws.
3.
Route the two antenna cables under the routing clips.
4.
Replace the
keyboard
.
5.
Replace the
center control cover
.
Display Bezel
Removing the Display Bezel
1.
Follow the instructions in "
Preparing to Work Inside the Computer
."
2.
Remove the
center control cover
.
3.
Remove the
keyboard
.
4.
.
5.
Use a plastic scribe to pry the six display bumpers out of the screw holes located on the front of the bezel.
6.
Remove the six M2.5 x 5-mm screws located on the front of the bezel.
NOTE:
Ensure that you route the antenna cables under the routing clips. Failure to do so could result in your keyboard not seating properly.
CAUTION:
Before you begin any of the procedures in this section, follow the safety instructions located in the Product Information Guide.
NOTICE:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal surface (such
as the back panel) on the computer.
