Installing the iSCSI bridge
Page 10 Dell Model TL24iSCSIxSAS 1Gb iSCSI to SAS User’s Guide Rev.C
6. Installing the iSCSI bridge
There are ten basic steps to install the iSCSI bridge on the Dell PowerVault TL2000:
• Remove the blue label that is securing the lock to the blank plate (on the rear panel of the library),
and then remove the shipping lock (see Figure 3).
Figure 3 Remove the shipping lock
• Store the blue label to the top of the library (see Figure 4) and store the shipping lock (see Figure 6).
Important: Before you undertake any work on the library, switch off the library and
remove the AC connector from the library.
Important: Hot plugging is not supported, the unit must be powered off for
installation of the iSCSI bridge card.
