360 DVS Series Direct Vent Fireplaces
10006326
584B
Vent components
Starter Kit
2/25/99 djt
584G
Venting Components
Firestop spacer
2/25/99 djt
584H
Venting components
attic insulation shield
2/25/99 djt
584I
vent components
offset support
2/25/99 djt
584F
Venting Components
Pipe sections
2/25/99 djt
10/20/99 twist lock
584E
Venting Components
Telescope vent
2/25/99 djt
10/20/99 twist lock
584D
Vent Components
90 degree elbow
2/25/99 djt
10/20/99 twist lock
584C
Vent components
45 degree elbow
2/25/99 djt
10/20/99 twistlock
584A
venting components
rear vent term
4/6/99 djt
7TDVRVT Through-the-Wall Rear Vent Termination
Starter Kit Model 7TDVSK - Sidewall
Starter Kit Model 7TDVSKV - Vertical Venting
for 7TDVSKV-A: order 1/12 to 6/12 roof pitch
for 7TDVSKV-B: order 7/12 to 12/12 roof pitch
for 7TDVSKV-F: order flat roof
Starter Kit Model 7TDVSKS - Snorkel Kit
Snorkel Termination - 7TDVSNORK
for Below Grade Installation
45˚ Elbow
7TDVT45 for Rear Vent to Vertical Vent
or Vertical/Horizontal Offsets
90˚ Transition Elbow
7TDVRT90 for Rear Vent to Vertical Vent
90° Elbow
7TDV90 Vertical/Horizontal Offset
Telescopic Vent Sections:
7TDVP1218 - 12” to 18” adjustable length
7TDVP3564 - 35” to 64” adjustable length
Pipe Sections for vertical or horizontal venting:
Model 7TDVP8” 4 per box
Model 7TDVP12” 4 per box
Model 7TDVP24” 4 per box
Model 7TDVP36”
Model 7TDVP48”
Firestop Spacer
Model 7DVFS
Attic Insulation Shield
Model 7DVAIS
Vertical/ Horizontal Combination Offset Support
Model 7DVCS
Twist Lock Venting Components
