A-1
Appendix A
FPIM Specifications
This MMAC-Plus module uses Fiber Port Interface Modules (FPIM) to provide
front panel cable connections. The FPIMs are user-installable. See the section
titled Installing an FPIM on page 2-1.
FPIM-00 and FPIM-01
The FPIM-00 and FPIM-01 provide a multimode fiber connection. The FPIM-00
uses a MIC style connector and the FPIM-01 uses an SC type connector. The
specifications for both devices are listed in Table A-1.
Table A-1. FPIM-00 and FPIM-01 Specifications
Parameter Typical Value
Worst
Case
Worst Case
Budget
Typical
Budget
Receive
Sensitivity -30.5 dBm -28.0 dBm — —
Peak Input
Power -7.6 dBm -8.2 dBm — —
