User-Accessible Components
User-Accessible Components
Figure 2-2 shows the various components that are accessible to the user. These
consist of an eight position dip switch (explained in the next section) and sockets
for replaceable PROMs. These will be used for future upgrades. Instructions for
installing the components will be supplied with the upgrade kit.
Figure 2-2. User-Accessible Components
SMB-1
PROM
DIP Switch
Boot PROM
