4-3
LANVIEW LEDs
The functions of the FDDI Port Status LEDs are listed in Table 4-2.
The functions of the FDDI Status LEDs are listed in Table 4-3.
Table 4-2. FDDI Port Status LEDs
LED Color STATE
Green Link, Active, Port Enabled
Yellow Link, Not Active, Port Enabled
Red Not Link, Port Disabled
Red (Flashing) Link, Port Disabled
Off No Link, Not Active, Port Enabled
Table 4-3. FDDI Status LEDs
LED Color State
Green Inserted
Red Isolated
Yellow Wrapped
Off Bypassed
