Installing the MicroLAN Module
2-4
Setting the Module Card DIP Switch
An eight switch DIP switch is located on the module card as shown in Figure 2-2
and Figure 2-3. The functions of the switches are listed in Table 2-1.
Figure 2-3. Location of Module DIP Switch
1
2
3
4
5
6
7
8
