Chapter 4
LANVIEW LEDs
The front panel LANVIEW LEDs indicate the status of the module and may be
used as an aid in troubleshooting. Shown in Figure 4-1 are the LANVIEW LEDs of
the 9F206-02 module.
Figure 4-1. 9F206-02 LANVIEW LEDs
A
1
9F206-02
FDDI
SMB
2
CPU
SMB and CPU
FDDI Port Status
