Centro 3800 User Manual

Page 17

16a. Place the cooking grates (BH) into the

burner box, as shown in fi gure A.

16b. Insert the three small positioning rods of

the warming rack (BI) into the rear panel of
the burner box.

17a. Insert the grease tray (CL) into the opening

in the upper back panel (CM), making sure
to engage tracks located under burner box.

17b. Place the grease cup (CK) onto the tracks,

located opn the underside of the grease
tray (CL).

ASSEMBLY INSTRUCTIONS
