ASSEMBLY INSTRUCTIONS
6
6. Attach the upper back panel (CM) to both the left
and right side panels (EA and EB).
Only install hardware in the bottom portion of the
back panel, as shown in fi gure B.
CM
Back view
7
7. Attach the right side shelf fascia (DH) to the right side
shelf table (DG), as shown.
EB
EA
B
#2 - ¼” - 20UNCx38 Screw (x2)
#4 - ø7 Lock Washer (x2)
#5 - ø7 Washer (x2)
DH
DG
#6 - NO. 10-24UNCx10 Screw (x3)
#7 - ø5 Lock Washer (x3)
#8. ø5 Washer (x3)
