CATEYE STRADA
Quick Start Manual
How to install the speed sensor
Fixing the wire
Adjust the clearance between
the speed sensor and magnet
Winding the wire
(Installation is completed)
Adjust the positions of the
speed sensor and magnet
Install the magnet
Install the speed sensor
Adjust the positions of the speed sensor
and magnet
Adjust the position so that the magnet passes
through the SENSOR LINE of the speed sensor.
After adjusting, tighten firmly the magnet.
Magnet
Speed sensor
(inside the front fork)
SENSOR LINE
