2
location is ideal for the maintenance
technician, and five access panels, easily
removed, provide quick and convenient
access to all components when needed.
As an added plus, all required service/
maintenance access can be from one
side allowing the unit to be located
against a wall or ceiling plenum obstruc-
tion, an obvious space-saving idea.
Carrier quality and reliability
The Carrier 50AH ROOMTOP® units
have much to offer the cost- and
efficiency-conscious commercial owner.
Every unit is thoroughly run tested at the
factory and equipped with safety controls
designed to monitor and protect over the
life of the unit.
Scroll compressor technology
Scroll compressors are designed for high
efficiency and are internally spring
mounted to minimize vibration noise.
Each compressor is hermetically sealed
against contamination to promote longer
life and dependable operation. Scroll
compressors are standard on all units.
Table of contents
Page
Features/Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1,2
Model Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
ARI Capacity Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Field-Installed Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Base Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Selection Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Performance Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9,10
Typical Wiring Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11,12
Typical Piping and Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Guide Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14,15
Model number nomenclature
ARI* capacity ratings
LEGEND
*Air-conditioning and Refrigeration Institute.
†TDR is standard.
NOTES:
1. Ratings are at zero condenser air static and rated in
accordance with ARI Standard 210.
UNIT
50AH
V-PH-Hz
TOTAL
kW
NET TOTAL
COOLING CAP. (Btuh)
NOMINAL
CFM
EER
SEER
SEER
(with TDR)
SOUND RATING
(dB)
024
230-1-60
2.56
24,800
800
—
—
10.50†
78
036
230-1-60
4.3
36,000
1200
—
10.00
10.00
82
208/230-3-60
8.40
—
—
460-3-60
8.40
—
—
048
230-1-60
5.63
49,500
1600
—
—
10.00†
82
208/230-3-60
8.80
—
—
460-3-60
8.80
—
—
060
230-1-60
6.9
58,500
2000
—
9.70
10.00
82
208/230-3-60
8.50
—
—
460-3-60
8.50
—
—
dB
—
Decibels
EER
—
Energy Efficiency Ratio
SEER —
Seasonal Energy Efficiency Ratio
TDR
—
Time-Delay Relay
2. EER =
NET CAPACITY (Btuh)
TOTAL WATTS
Indoor Fan Motor
– – Standard Motor
M – 1.5 hp Optional Motor
FIOP*
50AH
–
048 –
M
–
5
4
1
XX
Model Designation –
50AH Horizontal,
Indoor Single-Package
Cooling Unit
Packaging
1 – Domestic
2 – Export
Design Revision
Voltage
3 – 230-1-60
5 – 208/230-3-60
Nominal Tons
024 – 2
036 – 3
048 – 4
060 – 5
6 – 460-3-60
*FIOP — Factory-Installed option, contact your Carrier representative for details.
®
IS
O
90
01:2000 #A
23
2
5
Quality Assurance
