ELECTRIC HEATER DATA
LEGEND
*May be field converted to single-phase units, see electric heat installation instructions.
NOTE: Separate power source is required for all heaters. Control from base unit 50AH (24 v).
ELECTRIC HEATER
UNIT 88EN
USED WITH
UNIT 50AH
V-PH
(60 Hz)
CAP. (kW)
BRANCH CIRCUIT
Heater Amps
MCA
MOCP (Amps)
0050CA01
024, 036
1-Stage Heat
240-1
5.0
20.8
26.0
30
0075CA01
240-1
7.5
31.3
39.1
40
0115CA01
240-1
11.5
47.9
59.9
60
0075EA01
208-3
5.6
15.6
19.5
20
240-3
7.6
18.0
22.6
25
1150EA01
208-3
11.3
31.2
39.0
40
240-3
15.0
36.1
45.1
50
0100EA01
048, 060
2-Stage Heat
208-3
7.5
20.8
26.0
30
240-1*
10.0
41.7
52.1
60
240-3
10.0
24.1
30.1
35
0150EA01
208-3
11.3
31.2
39.0
40
240-1*
15.0
62.5
78.1
80
240-3
15.0
36.1
45.1
50
0200EA01
208-3
15.0
41.7
52.1
60
240-1*
20.0
83.3
104.2
110
240-3
20.0
46.9
58.6
60
0300EA01
208-3
22.5
62.5
78.2
80
240-3
30.0
72.2
90.2
100
0300CA01
240-1
30.0
124.0
155.0
175
0100FA01
480-3
10.0
12.0
15.0
15
0150FA01
480-3
15.0
18.1
22.6
25
0200FA01
480-3
20.0
24.1
30.1
35
0300FA01
480-3
30.0
36.1
45.1
50
MCA
— Minimum Circuit Ampacity
MOCP — Maximum Overcurrent Circuit Protection
(Fuses or Circuit Breaker)
