Base. en la ilustración 6-6 – Dell PowerEdge R300 User Manual
Page 185
Puentes y conectores
185
Ilustración 6-5.
Conector de tarjeta de expansión para tarjeta controladora secundaria
RAID SAS
Ilustración 6-6.
Conector de tarjeta de expansión para tarjetas RAC
1
Conectores de puerto externo
2
Ranura para módulo de memoria
1
Conector de llave TOE (44 patas)
2
Conector del cable de DRAC5
(50 patas)
3
Conector del puerto de NIC
Tarjeta SAS 5e
2
1
1
3
Tarjeta DRAC
2
