VRX745VD
61
English
Installation and Wire
connection manual
VRX745VD
Installation and Wire connection manual
■ Contents
1. BEFORE STARTING ............................................................... 61
2. PACKAGE CONTENTS ........................................................... 61
3. GENERAL CAUTIONS ............................................................ 62
4. CAUTIONS ON INSTALLATION .............................................. 62
5. INSTALLING THE MAIN UNIT ................................................. 63
6. REMOVING THE MAIN UNIT .................................................. 65
7. CAUTIONS ON WIRING .......................................................... 65
8. WIRE CONNECTION .............................................................. 66
9. SAMPLE SYSTEMS ................................................................ 69
1.
BEFORE STARTING
2.
PACKAGE CONTENTS
1. This set is exclusively for use in cars with a
negative ground 12 V power supply.
2. Read these instructions carefully.
3. Be sure to disconnect the battery “-”
terminal before starting. This is to prevent
short circuits during installation. (Figure 1)
Car battery
Figure 1
1 Main unit
2 Manuals
Owner’s manual & Installation manual
Warranty card
Guide label for SIRIUS radio
3 Power supply lead
4 Bag for accessories (No. 1)
Flat head screw (M5
× 8) ............................ 4
Sems hexagonal bolt (M5
× 8) ..................... 5
Electro tap
Machine screw (M4
× 3) ............................... 4
5 Bag for accessories (No. 2)
Hook plate ................................................... 2
Cord clamp
Rubber cap
Special screw
6 Universal mounting bracket
7 Remote control unit
8 Battery
(for remote control unit)
9 Outer Escutcheon
0 DCP Case
