VRX745VD

27

English

Owner

’s manual

Basic Operations

“COLOR”:
Adjust the color saturation.

• This operation is available only when the car

is stopped and the parking brake is applied.

4. Operate the touch key to adjust a level.

“BRIGHT”:
[

Î] Press to make image brighter

[

Å] Press to make image dimmer

“HUE”:
[

Î] Press to increase green

[

Å] Press to increase red

“COLOR”:
[

Î] Press to increase color depth

[

Å] Press to decrease color depth

5. Touch the [RTN] key, [ESC] key, or press the

[ADJ] button.

Adjusting the dimmer level

Use to adjust panel brightness when car lights
are ON/OFF.
The factory default:
When the car light is off: Brightest setting (58
steps)

When the car light is on: Medium brightness (29
steps)

1. When the panel is open, press the [ADJ]

button to display the ADJUST MODE menu.

2. Touch the [MONITOR] key, and touch the

[DIMMER LEVEL] key to adjust the dimmer
level.

3. Touch the [

О

О

О

О

О] or [Е

Е

Е

Е

Е] key to adjust.

4. Touch the [RTN] key, [ESC] key, or press the

[ADJ] button.

Warning display when CCD camera
is installed

When a TV tuner (sold separately) is installed
together with optional CCD camera, the
following warning message is displayed during
use of the CCD camera: “Make sure of safety
around your vehicle

∗ The factory default setting is “ON”

1. Press the [ADJ] button.

2. Touch the [MONITOR] key, and touch the

[CCD WARNING] key to switch between
ON” and “OFF”.

3. Touch the [RTN] key, [ESC] key, or press the

[ADJ] button.

Switching the VTR system between
NTSC and PAL

∗ This function is enabled only when the panel is

open.

∗ The factory default setting is “NTSC”.

Switch to the VISUAL/VTR in TV mode you use.

1. Press the [ADJ] button to switch to the

ADJUST MODE menu.

2. Touch the [MONITOR] key.

3. Touch the [NTSC/PAL] key to select “NTSC

or “PAL”.

4. Touch the [RTN] key, [ESC] key, or press the

[ADJ] button.

Switching the front and rear
monitor lock

The front monitor lock and rear monitor lock
allows you to enjoy 2-ZONE.

2-ZONE:

Use the front monitor lock (or rear monitor lock)
to lock the receiver screen image (or image
from a separately sold rear monitor) to switch
the speaker sound to a sound mode that differs
from the sound accompanying the image.

Notes:
• The front (rear) monitor lock displays the image of

an external device (VTR, TV game console, etc.)
connected to the Visual terminal.

• When 2-ZONE is used, the sound from an

external device (VTR, TV game console, etc.) can
only be heard from headphones connected to the
external device.

• A rear monitor is a separately sold accessory.

2-ZONE: 1 (front monitor lock)

1. Press and hold the [ADJ] button for 1 second

or longer.

2. Press the [FUNC] button to select the

desired mode.

3. To cancel the monitor lock, press the [ADJ]

button.

The screen shows the image of the selected
mode.
