10 Appendix
10.1 Technical data
for the combination POG 10 + DSL, HOG 10 + DSL, POG 11 + DSL, HOG 11 + DSL,
HOG 16 M + DSL, HOG 16 + DSL, HOG 165 + DSL
(version DSL.R or DSL.E)
permissible device temperature -20°C … +85°C (HOG 16 [M] + DSL, HOG 165 + DSL)
-30°C … +85°C (xOG 10 + DSL, xOG 11 + DSL)
max. speed in rpm electronic: mechanical: 6000
protection class IP 66 / IP 67 (HOG165 + DSL)
square-wave cycles / turn z 512, 1024, 2048, 2500
logic level HTL or TTL
max. switching frequency 120 kHz
switching speeds ns (DSL) ± 16 … 6000 rpm for z = 512
± 8 … 6000 rpm for z = 1024
± 4 … 3500 rpm for z = 2048
± 3 … 2900 rpm for z = 2500
maximum response time 40 msec
only for DSL.R
operating voltage UB +15 … +30 V DC
max. 200 mA (no load)
3 outputs high (12 V) for n < n
s
low (0 V) for n
≥ n
s
load capability per output: max. 20 mA
only for DSL.E
operating voltage UB +9 … +30 V DC
max. 200 mA (no load)
2 electronic make contacts closed for n < n
s
open for n
≥ n
s
230 V AC/DC, max. 250 mA
1 electronic make contact closed for “no error”
open for “error”
230 V AC/DC, max. 250 mA
7,2 x 10
6
z
