9 Log file
When altered data (switching points, password …) are saved in the DSL, an entry is made in the
C:\DSL_Parameter.txt log file.
Example: Entry for switching points
Serial number: 2271560481
Device type: POG10DN2500I+DSL.R
SW Version: 0.07
Last change:
Date: 06.04.2005
Time: 15:15:17
User: Tester
with password
Switched output 1:
Switching speed off n+ : 11 rpm
Switching speed on n+ : 6 rpm
Switching speed on n- : -6 rpm
Switching speed off n- : -8 rpm
Delay: 100 msec
Output activated
Switched output 2:
Switching speed off n+ : 8 rpm
Switching speed on n+ : 6 rpm
Switching speed on n- : -1800 rpm
Switching speed off n- : -1920 rpm
Delay: 120 msec
Output: activated
Switched output 3:
Switching speed off n+ : 1009 rpm
Switching speed on n+ : 800 rpm
Switching speed on n- : -1700 rpm
Switching speed off n- : -1921 rpm
Delay: 200 msec
Output: activated
