PA203
18 www.baumer.com
Second measured value
Requires manual entry in SCAL mode. In Teach mode, the value of
the provided analog signal will be adopted.
Assigning the displayed value a second measured value
The value requires manual entry using the keypad.
4.3 Programming lock
To access programming line “Programming lock” at the end of the
display configuration please proceed as follows:
Enter value „dSP2“ h and hold for 5 s. Enter character 0 or 1 at
“LC”.
Programming lock disabled
Programming lock enabled
Programming lock means programming lines are read only which will
be signaled by [dAtA] instead of [Pro] appearing in the display when
accessing programming level.
