6

AX430

6. REMOTE CONTROL

Remote control unit

Inserting the Batteries

1. Turn the remote control unit over, then slide

the rear cover in the direction of the arrow.

2. Insert the AA (UM-3/1.5V) batteries that came

with the remote control unit facing in the
directions shown in the figure, then close the
rear cover.

Notes:

Using batteries improperly can cause them to
explode. Take note of the following points:
• When replacing batteries, replace both batteries

with new ones.

• Do not short-circuit, disassemble or heat batteries.
• Do not dispose of batteries into fire or flames.
• Dispose of spent batteries properly.

[FUNC]

[DUAL ZONE]

[ ],[ ]

[ISR]

[MUTE]

[SCN]

[RPT]

[ ]

[ ],[ ]

[BAND]

[DISP]

[RDM]

Rear side

AA (UM-3/1.5V)
Batteries

Rear cover

Receiver for remote control unit

Operating range: 30˚ in all directions

Signal transmitter
