Clarion AX430 - Manual (Page 11)

AX430
13
8. IN CASE OF DIFFICULTY
Problem Cause Measure
Power does not turn on.
(or no sound is produced.) Fuse is blown. Replace with a fuse of the same
amperage as the old fuse.
Connections are improper. Read the attached “Installation/Wire
Connection Guide” once again and
wire properly.
Sound quality is poor. Playback head is dirty. Use a cleaning tape, etc. to clean the
head.
No sound while unit can
be operated. Power ANT lead is shorted
to the ground. Turn the unit off, first.
Remove all connecting wires from the
power ANT lead, and turn the unit on,
then re-connect a wire one by one to
the power ANT lead.
When sound is muted again, check
the unit with a wire connected last.
Error Display
ERROR 1
ERROR 2
ERROR 4
ERROR 8
ERROR 2
ERROR 3
ERROR 6
Cause
Tape cannot be played due to defective
tape such as cut tape.
Tape is caught and cannot be played.
Tape mode cannot be detected.
Tape is caught and cannot be ejected.
A CD inside the CD changer is not
loaded.
A CD inside the CD changer cannot be
played due to scratches, etc.
A CD inside the CD changer cannot be
played because it is loaded upside-
down.
Measure
Eject the tape then replace it with a new
one.
Remove the caught or wound tape.
This is a failure of tape mechanism and
consult your store of purchase.
Eliminate the reason for which the tape
is caught.
This is a failure of CD changer’s mecha-
nism and consult your store of pur-
chase.
Replace with a non-scratched, non-
warped disc.
Eject the disc then reload it properly.
T
ape
CD changer
If a display other than one of the displays above appears, press the reset button. If the problem per-
sists, turn the power off and contact your store of purchase.
9. ERROR DISPLAYS
If an error occurs, one of the following displays is displayed.
Take the measures described below to eliminate the problem.
