2. CONTROLS

Note:

Be sure to unfold this page and refer to the front diagrams as you read each chapter.

SOURCE UNIT

DISPLAY /

Cassette Insertion Slot

3

AX430

3. NOMENCLATURE

Note:

• Be sure to read this chapter referring to the front diagrams of chapter “2. CONTROLS” on page 3 (unfold).

Names of Buttons

4

AX430

AX430

25

INFORMATION FOR USERS:

.

CHANGES OR MODIFICATIONS TO THIS
PRODUCT NOT APPROVED BY THE MANU-
FACTURER WILL VOID THE WARRANTY AND
WILL VIOLATE FCC APPROVAL.

4. PRECAUTIONS

1. Tape slack can lead to operating difficulties.

Remove tape slack before inserting a cassette,
particularly when using C-90 or prerecorded
cassettes.

2. Use C-30 to C-90 cassettes. Avoid use of C-

120 or longer cassettes (The very thin tape
may stretch or break).

3. Clean the head periodically with a good com-

mercial head cleaner. Avoid touching the head
with magnetic or hard objects.

4. Do not oil the cassette mechanism.

5. Always remove the cassette from the mecha-

nism when not in use. Exposure to direct sun-
light, extreme temperatures or high humidity
may damage cassettes.

6. The cassette tape will automatically eject from

the mechanism if it is damaged. Always en-
sure that cassette tapes are in good condition
prior to use.

[RELEASE] button

[ROTARY] knob

[A-M] button

• Loudness button

[FNC] button

• Power button

[

Q] button

[ISR] button

[DISP] button

[RDM] button

[RPT] button

• Blank Skip button

[SCN] button

• Preset Scan/Auto Store button

[DIRECT] buttons (1 to 6)

[Z-EHCR] button

[BND] button

• Program button
• Magazine button

[

], [

] buttons

[

s ] button

• Mute button

Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
