Page 107: 106 instrument cluster

GAUGES
Cluster shown in standard measure – metric clusters similar.
A. Left Information Display
B. Speedometer
C. Right Information Display: See the MyTouch chapter for more
information.
Left Information Display
Odometer
Located in the bottom of the information display Registers the
accumulated distance your vehicle has travelled.
Outside air temperature
Shows the outside air temperature.
Trip Computer
See Trip Computer in Information Displays.
Vehicle Settings and Personalization
See Information Displays.
A
C
B
106
Instrument Cluster
2013 C-Max Full Hybrid (34h)
Owners Guide gf, 3rd Printing, January 2013
USA (fus)
