Description of transmitter parts – Dogtra 1200 Series User Manual
Page 6
9
TRANSMITTER
Transmitter Antenna
A short 2” antenna is supplied with the
.
The antenna should be screwed into the top of
the transmitter to ensure that the signals are sent
properly to the collar receiver and that maximum
range is attained.
2” Antenna
8
TRANSMITTER
Antenna
Indicator
Light
“Nick” Button
*
Toggle Switch
“Constant” Button
“Pager” Button
Intensity
Selection Dial
transmitter
indicates optional switch for 2 dog models
DESCRIPTION OF
TRANSMITTER PARTS
